Solar Panel Specifications |
|
|
Maximum Power (W) |
100W |
|
Optimum Power Voltage (Vmp) |
19.5 |
|
Optimum Operating Current (Imp) |
5.13 |
|
Open Circuit Voltage (Voc) |
22.7 |
|
Short Circuit Current (Isc) |
5.65 |
|
Cell Efficiency (%) |
22% |
|
Module Efficiency (%) |
>17.6% |
|
Tolerance Wattage(e.g.+/-3%) |
±3% |
|
NOCT |
47°C +/-2°C |
|
Dimensions (mm) |
850 x 680 x 30mm |
|
Technical Specifications |
|
|
Power |
Solar Power |
|
Input Voltage |
DC18/36V |
|
Output Voltage |
DC12/24V |
|
Heat Dissipation |
Air cooling or Natural cooling |
|
Surge Protection |
DC24,MAX 20KA |
|
Power Distribution Mode |
Customizable |
|
Dimensions |
850 x 680 x 30mm |
|
Solar Panel Quantity |
2 PCS |
|
Solar Panel Power |
100W |
|
Battery Capacity |
150 AH |
|
Lifting Height |
3 Meters |
|
Interface Port |
RS485 (Optional) |
|
Installation |
Floor Stand |
