Solar Panel Specifications |
|
|
Power Max (Pm) |
100W |
|
Power Max Voltage (Vmp) |
18.3W |
|
Power Max Current (Imp) |
5.47A |
|
Open Circuit Voltage (Voc) |
22.9V |
|
Short Circuit Current (Isc) |
5.92A |
|
Solar Panel Weight (Kg) |
6Kg |
|
Maximum System Voltage (V) |
600V |
|
Output Tolerance (%) |
±3% |
|
Dimensions (mm) |
850 x 680 x 30mm |
|
|
|
|
Technical Specifications |
|
|
Power |
Solar Power |
|
Input Voltage |
DC18/36V |
|
Output Voltage |
DC12/24V |
|
Heat Dissipation |
Air cooling or Natural cooling |
|
Surge Protection |
DC24, MAX 20KA |
|
Power Distribution Mode |
Customizable |
|
Dimensions (Cabinet) |
500 x 500 x 350mm |
|
Solar Panel Quantity |
1 PC |
|
Solar Panel Power |
100W |
|
Battery Capacity |
100 AH |
|
Lifting Height |
3 Meters |
|
Interface Port |
RS485 (Optional) |
|
Installation |
Floor Stand |
