XP-RT120BT20Battery Cabinet
It includes battery connection cables, breaker, terminal, etc, with maximum capacity of 20 pcs 12V/7AH or 12V/9AH batteries inside. The battery connection could be configured to output ±120V.
Battery Installation and Connection
Users need 20pcs batteries, divide into 2groups. Each group has 10pcs batteries in series, as (BAT+ BATN BAT-)shown below. 20pcs batteries installation and connection: There have five battery trays each fit 4pcs batteries, then connect the batteries as shown in below picture
